Comparison of F88SA2 (left) and EF88 (right) butt plates.
EF88 assault rifles in 16” and 20” barrel configurations.
Top: EF88 with 16” barrel shown with Ase Utra suppressor, Trijicon TA44SR-10 1.5×16 ACOG, and folding foregrip. Centre: EF88 with 20” barrel, fitted with Trijicon 4×32 BAC ACOG, Madritsch ML40AUS grenade launcher, and Thales Australia-designed quadrant sight with mounted Trijicon RMR. Bottom: F88SA2 (current Australian Defence Force service rifle) with RM Equipment M203PI grenade launcher, Knight’s Armament Company quadrant sight, and standard 1.5x ring sight.
Comparison of ML40AUS (top) and M203PI (bottom) grenade launchers. Note significantly better point of balance with new GLA, and unwieldy position of quadrant sight on old GLA.
Paul Williams test firing the ML40AUS grenade launcher mounted on a 20” barrel EF88. Note convenient, level placement of quadrant sight and mounted Trijicon RMR to left of ACOG.
EF88 with 16” barrel broken down into major component groups. Note hammer pack and retaining pin/rear sling swivel at centre. Ase Utra suppressor and ML40AUS grenade launcher also shown.
EF88 with 20” barrel in latest iteration, as seen at Land Warfare Conference 2012, with ML40AUS in matching two-tone colour scheme.
Bolt catch release, which will be fitted as standard on EF88 rifles acquired by Defence.
